Nominal Pressure: 300PSI
Conforms: ANSI / AWWA C515 Standard
Groove Standard: ANSI I AWWA C606 or Metric
Sizes: 2½”, 3″, 4″, 5″, 6″, 8″, 10″, 12″
Approvals: FM, UL, CUL, NSF/ANSI 61 & NSF/ANSI 372
Maximum Working Pressure: 300PSI (Maximum Testing Pressure: 600PSI) conforms to UL 262, ULC / ORD C262-92，FM 1120/1130
Maximum Working Temperature: 80°C/176°F
Coating Details: Epoxy coated interior and exterior by Electrostatic Spray or Coating upon request
NPT plug on body with 2 operating nuts
Certified lead-free by NSF I ANSI 61 & NSF 1 ANSI 372 is available
Z81-300
