Nominal Pressure: 300PSl
Conforms: ANSI 1 AWWA C515 Standard
Face to Face Standard : ASME B16.10
Sizes: 2½”, 3″, 4″, 5″, 6″, 8″, 10″, 12″
Flange Standard: ASME / ANSI B16.1 Class 125 or ASME / ANSI B16.42 Class 150 or BS EN1092-2 PN16 or GB/ T9113.1
Groove Standard: ANSI / AWWA C606 or Metric
Approvals: FM, UL, CUL, NSF /ANSI61 & NSFIANSI 372
Maximum Working Pressure: 300PSI (Maximum Testing Pressure: 600 PSI) conforms to UL262, ULC / ORD C262-92 , FM 1120/ 1130
Maximum Working Temperature: 80°C/ 176°F
Coating Details: Epoxy coated interior and exterior by Electrostatic Spray or Coating upon request
NPT plug on body with 2 operating nuts
Certified lead-free by NSF / ANSI 61 & NSF / ANSI 372 is available
Z481-300A
