Technical Features
Flange Standard:ANSI 125/150,DIN2501 PN10/16
Connection:Wafer End
Sizes:2″,2V2″,3″,4″,5″,6”,8″,10″,12″
Maximum Working Pressure:300 PSI (Maximum Testing Pressure:600 PSI)conforms to UL1091 &ULC/ORD-C1091 &FM 1112 Maximum Working Temperature:80°C/176°F
Application:Indoor &Outdoor Use,Fire inflow water,drainpipe,high-rising building firefighting system,industrial factory building fireprotection system
Coating Details:Epoxy coated interior and exterior by Electrostatic Spray or coating upon request
Disc:Ductile lron EPDM Rubber Encapsulated
Top Flange Standard:ISO 5211
Certified lead-free by NSF/ANSI 61 &NSF/ANSI 372 is available
